Thermostatic Constant Temperature Laboratory Orbital Shaking Incubator

FOB Reference Price:Get Latest Price
$1,800.00 - $2,600.00 / Unit | 1 Unit/Units (Min. Order)
Lead Time:
Quantity(Units) 1 - 15 >15
Est. Time(days) 25 Negotiable
Customization:
Customized logo (Min. Order: 5 Units)
Customized packaging (Min. Order: 5 Units)

More

Graphic customization (Min. Order: 5 Units) Less
Report Suspicious Activity
Overview
Quick Details
Classification:
Laboratory Thermostatic Devices
Brand Name:
Senova
Model Number:
DS-5013(2)/5033(2)
Place of Origin:
Shanghai, China
Product:
Thermostatic Laboratory Orbital Shaking Incubator for Lab
Model:
DS-5013(2)/5033(2)
Applications:
Parmaceutical industry and laboratory
Type:
Single Door Shaking Incubator
Temperature:
Thermostat Heating/Refrigeration
Speed Range:
RT+5℃-60℃/4℃-50℃
Flask Capacity:
48x50m to 12x1000ml
Shelf:
2 PCS
Display:
LCD
Power Supply:
220V/50Hz(Or,110V/60Hz)
Supply Ability
Supply Ability:
1200 Unit/Units per Year
Packaging & Delivery
Packaging Details
Plywood case.
Port
Shanghai, China
Lead Time :
Quantity(Units) 1 - 15 >15
Est. Time(days) 25 To be negotiated

Thermostatic Constant Temperature Laboratory Orbital Shaking Incubator

RT+5℃-60℃/4℃-60℃ Large Capacity Single Door Orbital Shaking Incubator with Double Decks

Model: DS-5013(RT+5℃-60℃)/DS-5033 (4℃-60℃)



Product Description

Applications

Research of biochemical reaction, enzyme

√Germ culture, ferment, hybridization and cellular tissue

√ Rresearch of medicine, biology, numerator, pharmacy, food and environmental protection.



Main Features

√Floor standing type with single door and double stainless steel decks

√Stainless steel flask clamps and chamber with illumination and UV lamp

√Powder-coated steel housing, front open door with big glass window

√LCD display (with backlight) of set and working parameters

√Single-shaft drive technology, quite and durable

√Speed range extensible to 30-300rpm

√2 options: refrigeration  (4C to 60C: DS-5033) or heating (RT+5C to 60C: DS-5013)

√CFC-free (R134a) refrigerant (DS-5033)

√Timing up to 999.59 hours, with acoustic and visual alarm

√High/low limit over speed alarm

√High/low limit over temperature acoustic & visual alarm

√Stop-running protection for door opening

√Electric current leakage and over load protection

√Motor over-heat protection

√Automatic power cut-off in case of temperature out of control or abnormal over-temperature

√Repeat, increment (step) and 8-segment curve programming setting

√Power-failure recovery, parameter memory, temperature/speed calibration, time display, and room/working temperature display.

√Acceleration control circuit ensures soft start, smooth acceleration and safety of samples

√120W AC inductive long-life brushless motor, with wide speed regulation, constant torque, constant speed of rotation, and maintenance-free

√Safety protection of automatic stop of shaking when door is opened

√Standard accessory:Fluorescent lamp, UV lamp, shaking tray, flask clamp



Specifications

Model

DS-5013

DS-5033

Control

P.I.D.(Environmental Scanning Microprocessor)

Display

LCD(simultaneous display of working & set parameters)

Convection Mode

High Speed Circulation

Oscillation Mode

Revolution

Revolution

Drive

Single-shaft balance device

Working Environment

Temperature: 25℃.Humidity20%-90%

Door Opening

Single Door

Temp. Range

RT+5℃~60℃

4℃~60℃

Temp. Accuracy

±0.1℃

Temp. Uniformity

±1℃

Speed Range(rpm)

30-300

Speed Accuracy

±1rpm

Orbit

Φ25mm

Φ25mm

Refrigerant

/

R134a

Cooler Power

/

200W

Heater Power

500W

500W

Timing Range

0-999.59hr/Continuous

Tray Size(mm)

500x350

500x350

Tray Number

2 PCS

Tray Material

Stainless steel (with steel rack)

Net Weight

150Kg

165Kg

Chamber Size

60x44x65

60x44x65

(DxWxH,cm)

Overall Dimensions

70x60x125

70x60x125

(DxWxH,cm)

Power

600W

830W

Power Supply

AC 200-240V/50-60Hz. Optional: AC110V/60Hz

Chamber Material

Polished stainless steel

Construction

Powder Coated Steel Housing









Company Profile

With R&D and production base in Shanghai as well as over 15 years of experience in international market for constant temperature laboratory equipment (thermal chamber), Senova is the international sales center to serve our global distributors with both reliable products complying with international standard and after-sales service.



FAQ

1. Are you a factory or trading company ?

 A : We are a factory with an international sales company specialized in support for global distributors. Please find our third-party factory audit (verfification) report shown above.



2 .Where is your company location ? How can we visit there ?

 A :Our factory is in Shanghai, the most booming city in China , 20Km away from Shanghai Pudong International Airport. Welcome to visit us !



3. What certification do you have?

 A : ISO 9001 and CE certificate.

Our Services

After-sales service

     Technical support for any enquiry for troubleshooting

     Quick supply of spare parts ensured

     Service training provided if necessary



Warranty and support

     14-month standard warranty

     Prompt technical support and fast supply of spare parts from stock

     Maintaining stock for fast delivery of the goods for regular orders

     Opportunities for exclusive distributorship

     Enquiry forwarding

     New model and product launch

     Website download service of updated product information on  brochures, price, etc.

     Special price support for big project

     Exclusive tender authorization offered upon request

     Provision of promotion material like product images and minimum brochures

     Demo units at special price

     Award discount policy

     Sales and service training

     Training material

     Electronic user & service manual

     Exhibitions cooperation
